240V 5KW UPS Battery System Backup System Uninterrupted Power Supply

240V 5KW UPS Battery System Backup System Uninterrupted Power Supply
240V 5KW UPS Battery System Backup System Uninterrupted Power Supply

Large Image :  240V 5KW UPS Battery System Backup System Uninterrupted Power Supply

Product Details:
Place of Origin: China
Brand Name: Qiyuan
Certification: CE, IEC, MSDS, UN38.3
Model Number: UPJ5k5DD-240
Document: Product Brochure PDF
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: USD/CNY, Unit
Packaging Details: wooden case
Delivery Time: 1-2 months
Payment Terms: L/C, T/T
Supply Ability: 500 set per month
Contact Now

240V 5KW UPS Battery System Backup System Uninterrupted Power Supply

Description
Battery Type: LFP Battery Rated Power: 1-10KW
Power Factor: 0.9 Frequency: 45~60Hz
Rated Voltage: 220/230/240VAC Voltage Range: 140~295VAC
No. Of Phases: Single Phase 3 Wire Efficiency: >96%
Battery Voltage: 38.4-51.2VDC Life Cycle: 3000 Times
Installation: Rack/tower Application: UPS System, Back Up Power
OEM/customization: Acceptable
Highlight:

240v battery backup system

,

5KW UPS Battery System

,

Uninterrupted battery backup system

  • Output power factor as high as 0.9, load ability;
  • Efficiency above 95%;
  • Use DSP digital control technology, pure sine wave power supply is stable and reliable;
  • Use high stability of the lithium iron phosphate batteries, safe and reliable;
  • Lithium battery management solutions for special purpose, with triple loop over voltage protection, preset temperature, pressure switch interface;
  • Discharge temperature range can reach to -20 ℃ to 50 ℃;
  • 90 ~ 300 v ultra-wide input voltage and 40 ~ 70 hz frequency, wide frequency can be set for generator application;
  • Intelligent configuration, supports output for transformer voltage compensation;
  • RS485, RS232, communication function;
Model UPJ1KDD-220-36 UPJ2KDD-220-48 UPJ3KDD-220-48 UPJ6KDD-220-48 UPJ10KDD-220-192
Power KVA/KW 1/0.9 2/1.8 3/2.7 6/5.4 10/9
Input
Rated voltage 220/230/240VAC(configurable)
Voltage range 140~295±5VAC(100%),90~140VAC (50%)
Frequency 45~60HZ
Power factor 0.99
Standard current 4A 9A 13A 27A 45A
Harmony wave distortion ≤6% ≤5%
Output
No of phases Single phase 3 wire L+N+PE
Rated voltage 220/230/240VAC(configurable)
Voltage accuracy ±1%
Output frequency accuracy

Grid input mode:Sync with bypass input；

Battery mode:50/60Hz±1%
Output power factor 0.9
Total voltage harmony wave distortion Linear load＜3%,non-linear load＜5%
Load peak ratio 3:1
Overload capacity: Grid input

Continuous <110%,110~130% for 1min,130~150% for 10S,

150% and above for 200ms
Overload capacity: battery

Continuous <105%,105~130% for 1min,130~150% for 3S,

150% and above for 200ms
System
System efficiency Online＞90%,ECO＞94% Online＞92%,ECO＞96%
Replace time 0ms
Communication RS232(standard),optional:USB, SMNP, RS485, dry contact
Display LCD
Battery
DC voltage 36 48 48 48 192
Battery (LFP) 38.4V6AH 51.2V12AH 51.2V18AH 51.2V30Ah -
Battery structure Rack/tower Tower -
Continuous charging current 4~8A 10~40A 4~12A
Rack size 482*320*86 482*430*86 480*450*132 480*450*86 482*420*86
Tower size 300*145*232 380*190*232 412*190*220 460*190*310 -
Work/test temperature -10~45℃/-25~55℃
Noise ＜50dB



Tag:

10KW uninterruptible power system,

240v uninterruptible power system,

lfp ups backup power system
