Product Details:
|
| Battery Type: | Lifepo4 Battery | Enclosure Material: | ABS |
|---|---|---|---|
| IP Level: | IP67 | Rated Voltage: | 24V |
| Discharge Current: | 30A | Warranty: | 3 Years |
| Application: | Backup Power, Replacement Of Lead Acid Battery | Nominal Capacity: | 24Ah - 400ah |
| Cycle Life: | > 3000 Times | Rated Capacity: | 30Ah |
| Compact Desiged: | With Built-in BMS | Operating Temperature: | -20℃-60℃ |
| Highlight: | 30ah lifepo4 lithium ion battery,portable 24v 30ah lifepo4 battery,24v lifepo4 lithium ion battery |
||
24V 30AH Portable LiFePo4 Battery lithium battery
Product Features:
| Model | TE24-12 | TE24-30 | TE24-42 | TE24-54 | TE24-78 | TE24-100 | TE24-120 |
| Voltage (VDC) | 25.6 | ||||||
| Capacity (WH) | 307 | 768 | 1075 | 1382 | 1996 | 2560 | 3072 |
| Charging current (A) | 6 | 12 | 20 | 25 | 40 | 50 | 50 |
| Discharging current (A) | 12 | 30 | 50 | 50 | 80 | 100 | 100 |
| Charging voltage (V) | 28.4 | ||||||
| Protection voltage (V) | 20.8 | ||||||
| Working temperature | Charging temperature 0~45℃,discharging temperature -20~60℃ | ||||||
| Protection level | IP67 | ||||||
| Dimension | 181*77*167 | 229*138*217 | 260*168*209 | 330*172*214 | 483*170*240 | 522*240*218 | 520*269*220 |
| Weight | |||||||
