Product Details:
|
| Battery Type: | Lifepo4 Battery | Enclosure Material: | ABS |
|---|---|---|---|
| IP Level: | IP67 | Rated Voltage: | 48V |
| Discharge Current: | 30A | Warranty: | 3 Years |
| Application: | Backup Power, Replacement Of Lead Acid Battery | Nominal Capacity: | 24Ah - 400ah |
| Cycle Life: | > 3000 Times | Rated Capacity: | 30Ah |
| Compact Desiged: | With Built-in BMS | Operating Temperature: | -20℃-60℃ |
| Highlight: | 24AH Portable Lifepo4 Battery,UPS 48v 24ah lifepo4 battery,portable 48v 24ah lifepo4 battery |
||
48V 24AH Portable LiFePo4 Battery lithium battery
Product Features:
| Model | TE48-12 | TE48-24 | TE48-30 | TE48-42 | TE48-54 | TE48-60 | TE48-72 |
| Voltage (VDC) | 51.2 | ||||||
| Capacity (WH) | 307 | 1228 | 1536 | 2150 | 2765 | 3072 | 3686 |
| Charging current (A) | 6 | 12 | 15 | 20 | 20 | 30 | 30 |
| Discharging current (A) | 12 | 30 | 30 | 50 | 50 | 80 | 80 |
| Charging voltage (V) | 56.8 | ||||||
| Protection voltage (V) | 41.6 | ||||||
| Working temperature | Charging temperature 0~45℃,discharging temperature -20~60℃ | ||||||
| Protection level | IP67 | ||||||
| Dimension | 229*138*217 | 330*172*214 | 483*170*240 | 483*170*240 | 522*240*218 | 520*269*220 | 520*269*220 |
| Weight | |||||||
