Product Details:
|
Voltage: | Varies Depending On Model | Communication Protocol: | Modbus, CAN, Ethernet |
---|---|---|---|
Capacity: | Varies Depending On Model | Model: | Energy Storage System |
Dimensions: | Varies Depending On Model | Ess Container: | 20ft |
Function: | Backup Power, Peak Load Shifting | Efficiency: | Up To 98% |
Highlight: | 20ft Commercial Energy Storage,100KW Commercial Energy Storage Systems,215KWH bess system |
This series of products is designed specifically for inverters, DC loads, and DC power storage by our company. Utilizing safe and reliable LiFePO4 batteries, this series is characterized by excellent safety and durability. The product is structured with a two-tier architecture, consisting of cells, modules, and systems that together create a comprehensive communication and management system. Additionally, it operates with a parallel two-tier architecture and offers remote data acquisition, analysis, control, alarm, and protection functions.
Lithium iron phosphate batteries meet the CE standard.
Product safety No fire after thermal runaway and integrated module-level fire protection;
Equipped with Level 3 fire protection;
With direct parallel connection between clusters;
3 or more clusters in parallel, with fault exit mechanism;
Remote monitoring and maintenance functions;
Fit both indoor and outdoor scenarios.
Suitable for a variety of mainstream hybrid inverters.
Suitable for DC loads, energy storage converters, and inverters.
Designed for special battery applications.
Product Customization Services for the BESS Energy Storage System:
Brand Name: QIYUAN
Model Number: EST100KW-215KWH
Place Of Origin: China
Certification: UN38.3, IEC
Minimum Order Quantity: 1
Packaging Details: Container
Supply Ability: 20 Units/Month
Model: Energy Storage System
Communication Protocol: Modbus, CAN, Ethernet
Certifications: CE, UL, TUV
Battery: LiFePo4
Application: Renewable Energy Integration, Grid Stabilization, Backup Power
EST050512- 100WP |
EST100512- 200WP |
EST160512- 200WP |
EST241768- 200WP |
|
Battey parameters |
||||
Rated Voltage |
512VDC |
512VDC |
512VDC |
768VDC |
Capacity |
51KWH |
102KWH |
160KWH |
241KWH |
Charging voltage |
552~560VDC |
552~560VDC |
552~560VDC |
828~840VDC |
Discharge voltage |
448~576VDC |
448~576VDC |
448~576VDC |
672~864VDC |
Max charging current |
100A |
150A |
150A |
150A |
Max discharging current |
120A |
200A |
200A |
200A |
Battery cycles |
4000 |
4000 |
6000 |
6000 |
DOD |
80% |
|||
System parameters |
||||
Working temperature |
-30~50℃(derate above 50℃) |
|||
Storage temperature |
0~40℃ |
|||
Humidity |
0~95% no condensation |
|||
Control mode |
EMS and remote control |
|||
Cooling |
Smart HVAC |
|||
Fire protection system |
Module-level aerosol / heptafluoropropane |
|||
System protection |
With an emergency power-off protection function. |
|||
Installation / IP level |
Outdoor / IP54 |
|||
Communication |
Ethernet / CAN / RS485 |
|||
Altitude |
2000m,derate above 2000m |
|||
Dimensions |
800*1200*2200 |
1300*1200*2000 |
1300*1200*2300 |
|
Weight |
750KG |
1100KG |
1450KG |
2050KG |
Certification |
UN38.3 |
|||
Standards |
Meets IEC62619 ICE61000 |
