Product Details:
|
Warranty: | 5 Years | Weight: | Varies Depending On Model |
---|---|---|---|
Cycle Life: | Up To 6,000 Cycles | Dimensions: | Varies Depending On Model |
Ess Container: | 20ft | Voltage: | Varies Depending On Model |
Certifications: | CE, UL, TUV | Efficiency: | Up To 98% |
Highlight: | Grid Stabilization bess battery,Modbus Communication Protocol bess system |
This series of products is a special line designed by our company for a variety of inverters, DC loads, and DC power storage systems. The products are equipped with safe and dependable LiFePO4 batteries that offer excellent safety and a long lifespan.
The unique design of this series incorporates a two-tier architecture, where cells, modules, and systems work together to create a comprehensive communication and management system. Additionally, the products feature a parallel two-tier architecture to enhance performance.
One of the key highlights of this series is its advanced functionalities, including remote data acquisition, analysis, control, alarm systems, and protection mechanisms. These features provide enhanced convenience and reliability for users.
Lithium iron phosphate batteries conform to the CE standard. They are designed with product safety features such as no fire occurrence after thermal runaway and an integrated module-level fire protection system. These batteries come equipped with Level 3 fire protection and have a direct parallel connection between clusters. When using 3 or more clusters in parallel, they incorporate a fault exit mechanism for added safety.
For convenient management, these batteries offer remote monitoring and maintenance functions. Their versatile design allows them to be suitable for both indoor and outdoor applications, providing flexible and efficient power storage solutions.
These products are compatible with a range of popular hybrid inverters. They are also suitable for use with DC loads and energy storage converters. Additionally, they can be utilized with inverters and for special battery applications.
Product Customization Services for the BESS Battery Energy Storage System:
Brand Name: QIYUAN
Model Number: EST 100KW-215KWH
Place Of Origin: China
Certification: UN38.3, IEC
Minimum Order Quantity: 1
Packaging Details: Container
Supply Ability: 10 Units/Month
Application: Renewable Energy Integration, Grid Stabilization, Backup Power
Dimensions: Varies Depending On Model
Cycle Life: Up To 6,000 Cycles
Weight: Varies Depending On Model
Certifications: CE, UL, TUV
Model |
EST050512- 100NP |
EST100512- 200NP |
EST160512- 200NP |
EST241768- 200NP |
Battey parameters |
||||
Rated Voltage |
512VDC |
512VDC |
512VDC |
768VDC |
Capacity |
51KWH |
102KWH |
160KWH |
241KWH |
Charging voltage |
552~560VDC |
552~560VDC |
552~560VDC |
828~840VDC |
Discharge voltage |
448~576VDC |
448~576VDC |
448~576VDC |
672~864VDC |
Max charging current |
100A |
150A |
150A |
150A |
Max discharging current |
120A |
200A |
200A |
200A |
Battery cycles |
90% |
|||
System parameters |
||||
Working temperature |
-0~40℃(derate above 440℃) |
|||
Storage temperature |
0~40℃ |
|||
Humidity |
0~95% no condensation |
|||
Control mode |
EMS and remote control |
|||
Cooling |
Natural air |
|||
Fire protection system |
Module-level aerosol |
|||
System protection |
With an emergency power-off protection function |
|||
Installation / IP level |
Indoor / IP20 |
|||
Communication |
Ethernet /CAN /RS485 |
|||
Altitude |
2000m,derate above 2000m |
|||
Dimensions |
600*1000*2000 |
1100*1000*2000 |
1100*1200*2300 |
|
Weight |
1100KG |
1220KG |
2650KG |
2930KG |
Certification |
UN38.3 |
|||
Standards |
Meets IEC62619 ICE61000 |
