Product Details:
|
Ess Container: | 20ft | Voltage: | Varies Depending On Model |
---|---|---|---|
Cycle Life: | Up To 6,000 Cycles | Certifications: | CE, UL, TUV |
Dimensions: | Varies Depending On Model | Weight: | Varies Depending On Model |
Application: | Renewable Energy Integration, Grid Stabilization, Backup Power | Function: | Backup Power, Peak Load Shifting |
Highlight: | Optimize Grid Performance BESS,6000 Cycle Life BESS,LIFEPO4 bess battery storage |
This series of products is specifically designed by our company for use with various inverters, DC loads, and DC power storage. We utilize safe and reliable LiFePO4 batteries in this series, ensuring good safety and long life of the products. The design incorporates a two-tier architecture, with cells, modules, and systems working together to create a comprehensive communication and management system. The system also includes parallel two-tier architecture, enabling remote data acquisition, analysis, control, alarm functions, and protection features.
- Lithium iron phosphate batteries are compliant with the CE standard.
- The product ensures safety, with no fire occurring after thermal runaway and an integrated module-level fire protection system.
- It is equipped with Level 3 fire protection and allows for a direct parallel connection between clusters.
- The battery system supports 3 or more clusters in parallel and includes a fault exit mechanism.
- Additional features include remote monitoring and maintenance functions, catering to both indoor and outdoor applications.
Suitable for a variety of mainstream hybrid inverters.
Suitable for DC loads.
Energy storage converters.
Suitable for inverters.
Special battery applications.
Product Customization Services for the BESS Battery Energy Storage System:
Brand Name: QIYUAN
Model Number: EST100KW-215KWH
Place Of Origin: China
Certification: UN38.3, IEC
Minimum Order Quantity: 1
Packaging Details: Container
Supply Ability: 5 Units/Month
Warranty: 5 Years
Application: Renewable Energy Integration, Grid Stabilization, Backup Power
Model: Energy Storage System
Cycle Life: Up To 6,000 Cycles
Voltage: Varies Depending On Model
Keywords: Battery Energy Storage System, Energy Battery Storage, All In One Energy Storage System
Model |
EST050512- 100NP |
EST100512- 200NP |
EST160512- 200NP |
EST241768- 200NP |
Battey parameters |
||||
Rated Voltage |
512VDC |
512VDC |
512VDC |
768VDC |
Capacity |
51KWH |
102KWH |
160KWH |
241KWH |
Charging voltage |
552~560VDC |
552~560VDC |
552~560VDC |
828~840VDC |
Discharge voltage |
448~576VDC |
448~576VDC |
448~576VDC |
672~864VDC |
Max charging current |
100A |
150A |
150A |
150A |
Max discharging current |
120A |
200A |
200A |
200A |
Battery cycles |
90% |
|||
System parameters |
||||
Working temperature |
-0~40℃(derate above 440℃) |
|||
Storage temperature |
0~40℃ |
|||
Humidity |
0~95% no condensation |
|||
Control mode |
EMS and remote control |
|||
Cooling |
Natural air |
|||
Fire protection system |
Module-level aerosol |
|||
System protection |
With an emergency power-off protection function |
|||
Installation / IP level |
Indoor / IP20 |
|||
Communication |
Ethernet /CAN /RS485 |
|||
Altitude |
2000m,derate above 2000m |
|||
Dimensions |
600*1000*2000 |
1100*1000*2000 |
1100*1200*2300 |
|
Weight |
1100KG |
1220KG |
2650KG |
2930KG |
Certification |
UN38.3 |
|||
Standards |
Meets IEC62619 ICE61000 |
