Product Details:
|
Ess Container: | 20ft | Certifications: | CE, UL, TUV |
---|---|---|---|
Weight: | Varies Depending On Model | Function: | Backup Power, Peak Load Shifting |
Cycle Life: | Up To 6,000 Cycles | Warranty: | 5 Years |
Model: | Energy Storage System | Battery: | LiFePo4 |
Highlight: | LiFePo4 BESS Battery Energy Storage System,LiFePo4 bess storage,LiFePo4 bess energy storage |
This series of products is designed by our company specifically for different inverters, DC loads, and DC power storage applications. The products incorporate safe and reliable LiFePO4 batteries, ensuring good safety and long lifespan. They are structured with a two-tier architecture, consisting of cells, modules, and systems that together create a comprehensive communication and management system.
The products operate on a dual-tier architecture in parallel and offer various functions such as remote data acquisition, analysis, control, alarm, and protection. These features make them suitable for a range of industrial and commercial applications where efficient power storage and management are essential for optimal performance.
Lithium iron phosphate batteries comply with the CE standard . They are designed with product safety features such as no fire risk following thermal runaway, integrated module-level fire protection, and Level 3 fire protection. The batteries are equipped with direct parallel connections between clusters, as well as a fault exit mechanism when operating with 3 or more clusters in parallel.
Moreover, these batteries are equipped with remote monitoring and maintenance functions , making it convenient and efficient to keep track of their performance and address any issues.
With their versatility, they are suitable for both indoor and outdoor applications , providing reliable power solutions for various scenarios.
These products are suitable for a variety of mainstream hybrid inverters.
They can also be used for DC loads, energy storage converters, and inverters, making them versatile for different applications. Additionally, they are ideal for special battery requirements.
Product Customization Services for the BESS Battery Energy Storage System:
Brand Name: QIYUAN
Model Number:EST100KW-215KWH
Place Of Origin: China
Certification: UN38.3, IEC
Minimum Order Quantity: 1
Packaging Details: Container/Enclosure
Supply Ability: 10 Units/Month
Communication Protocol: Modbus, CAN, Ethernet
Function: Backup Power, Peak Load Shifting
Fire System: Yes
Certifications: CE, UL, TUV
Warranty: 5 Years
Model |
EST050512- 100NP |
EST100512- 200NP |
EST160512- 200NP |
EST241768- 200NP |
Battey parameters |
||||
Rated Voltage |
512VDC |
512VDC |
512VDC |
768VDC |
Capacity |
51KWH |
102KWH |
160KWH |
241KWH |
Charging voltage |
552~560VDC |
552~560VDC |
552~560VDC |
828~840VDC |
Discharge voltage |
448~576VDC |
448~576VDC |
448~576VDC |
672~864VDC |
Max charging current |
100A |
150A |
150A |
150A |
Max discharging current |
120A |
200A |
200A |
200A |
Battery cycles |
90% |
|||
System parameters |
||||
Working temperature |
-0~40℃(derate above 440℃) |
|||
Storage temperature |
0~40℃ |
|||
Humidity |
0~95% no condensation |
|||
Control mode |
EMS and remote control |
|||
Cooling |
Natural air |
|||
Fire protection system |
Module-level aerosol |
|||
System protection |
With an emergency power-off protection function |
|||
Installation / IP level |
Indoor / IP20 |
|||
Communication |
Ethernet /CAN /RS485 |
|||
Altitude |
2000m,derate above 2000m |
|||
Dimensions |
600*1000*2000 |
1100*1000*2000 |
1100*1200*2300 |
|
Weight |
1100KG |
1220KG |
2650KG |
2930KG |
Certification |
UN38.3 |
|||
Standards |
Meets IEC62619 ICE61000 |
