Product Details:
|
Certifications: | CE, UL, TUV | Cycle Life: | Up To 6,000 Cycles |
---|---|---|---|
Ess Container: | 20ft | Communication Protocol: | Modbus, CAN, Ethernet |
Capacity: | Varies Depending On Model | Application: | Renewable Energy Integration, Grid Stabilization, Backup Power |
Dimensions: | Varies Depending On Model | Efficiency: | Up To 98% |
Highlight: | 98% Efficiency Battery Storage System,215KWH Battery Energy Storage System,215KWH bess energy |
This series of products is the specific product line of our company that is specially tailored for different inverters, DC loads, and DC power storage applications. The series is equipped with safe and dependable LiFePO4 batteries, ensuring excellent safety and extended lifespan. Utilizing a two-tier architecture, the system comprises cells, modules, and overall systems that together create a comprehensive communication and management setup. This architecture is designed in parallel, offering remote data acquisition, analysis, control, alarm, and protection functionalities.
These products are compatible with a range of popular hybrid inverters. They are also suitable for use with DC loads and energy storage converters. In addition, they can be used with inverters and are designed for special battery applications.
l Product features
- Battery system complies with the CE standard.
- safe and will not cause a fire after thermal runaway, and it integrates module-level fire protection; it has a three-level fire protection system.
- Function of direct parallel connection between clusters.
- Three or more clusters in parallel, with a fault withdrawal mechanism.
- Remote monitoring and maintenance functions
- Applicable for both indoor and outdoor scenarios.
Product Customization Services for the BESS Battery Energy Storage System:
Brand Name: QIYUAN
Model Number: EST 100KW-215KWH
Place Of Origin: China
Certification: UN38.3, IEC
Minimum Order Quantity: 1
Packaging Details: Container/Enclosure
Supply Ability: 10 Units/Month
Communication Protocol: Modbus, CAN, Ethernet
Efficiency: Up To 98%
Ess Container: 20ft
Voltage: Varies Depending On Model
Function: Backup Power, Peak Load Shifting
Keywords: Energy storage battery, Industrial and Commercial Energy Storage System, ESS Energy Storage System
EST050512- 100WP |
EST100512- 200WP |
EST160512- 200WP |
EST241768- 200WP |
|
Battey parameters |
||||
Rated Voltage |
512VDC |
512VDC |
512VDC |
768VDC |
Capacity |
51KWH |
102KWH |
160KWH |
241KWH |
Charging voltage |
552~560VDC |
552~560VDC |
552~560VDC |
828~840VDC |
Discharge voltage |
448~576VDC |
448~576VDC |
448~576VDC |
672~864VDC |
Max charging current |
100A |
150A |
150A |
150A |
Max discharging current |
120A |
200A |
200A |
200A |
Battery cycles |
4000 |
4000 |
6000 |
6000 |
DOD |
80% |
|||
System parameters |
||||
Working temperature |
-30~50℃(derate above 50℃) |
|||
Storage temperature |
0~40℃ |
|||
Humidity |
0~95% no condensation |
|||
Control mode |
EMS and remote control |
|||
Cooling |
Smart HVAC |
|||
Fire protection system |
Module-level aerosol / heptafluoropropane |
|||
System protection |
With an emergency power-off protection function. |
|||
Installation / IP level |
Outdoor / IP54 |
|||
Communication |
Ethernet / CAN / RS485 |
|||
Altitude |
2000m,derate above 2000m |
|||
Dimensions |
800*1200*2200 |
1300*1200*2000 |
1300*1200*2300 |
|
Weight |
750KG |
1100KG |
1450KG |
2050KG |
Certification |
UN38.3 |
|||
Standards |
Meets IEC62619 ICE61000 |
