Product Details:
|
Enclosure: | Container, Or Customized | Capacity: | 500KWH Up To 1.37 MWH |
---|---|---|---|
PCS Power: | 500KW | Battery: | LiFePo4 |
Module: | 51.2V 105AH | Output Voltage: | 380/400/415VAC |
Discharge: | 0.5C/1C | HVAC: | Yes |
Fire System: | Yes | Dimension: | 20 Feet Container With Shipping Certificate |
Shipping: | Battery In The Container | UN Code: | UN3536 |
High Light: | lifepo4 bess battery energy storage,lifepo4 ess container,500kwh ess container |
ESS series BESS system provides integrated energy storage technology, serves perfectly for commercial and industrial enegry storage application.
- Provide a cost-effective way to store excess energy generated from renewable sources.
- Can store excess electricity generated by renewable energy sources , allowing it to be used at a later time when these sources are not available.
- BESS can provide backup power during outages or extreme weather events, reducing the need for costly distribution upgrades or emergency generators.
- Assist in load leveling and grid support, helping to balance fluctuations in electricity demand throughout the day.
- Bess can improve power quality by smoothing out voltage fluctuations that may otherwise disrupt equipment operations.
- Effortless installatino, making them a popular choice for businesses looking for reliable energy storage systems.
Model | ESS500-380-1290 | ESS500-380-1350 |
Rated output power | 500KW | 500KW |
Rated grid voltage | 380/400/415V | |
Input voltage range | 320~460VAC | |
Output voltage range | 380/400/415VAC | |
Frequency | 50/60HZ | |
AC pattern | 3W+N+PE | |
Grid switching time | <20ms | |
System voltage | 768 | 810 |
Battery module model | 51.2V210Ah | |
Battery cluster capacity | 161.3 | 172 |
No. of paralleled clusters | 8 | |
EMS | Yes | |
Dry pipe fire extinguishing | Yes | |
Fire alarm | Yes | |
Fire alarm | Yes | |
HVAC | Yes | |
Access control | Yes | |
Remote control | Yes | |
Peak-valley calculation | Yes | |
Communication | CAN,RS485 | |
Protection value | IP54 | |
PCS unit cooling | Forced air | |
Working temperature | -30~55℃ | |
Maintenance | External maintenance | |
Dimension | 6058*2400*2900 | |
Weight MT | 24 | 26 |
